Plan any floor. Cut with confidence.
TileLay turns any room shape into a precise, numbered layout for laminate, decking, and tiles — with a full cut list and printable PDF plan.
- Draw any polygonFreehand rooms or DXF import
- Cut list & wasteNumbered pieces + order qty
- Printable PDFTake it to the workshop
Laminate mode — male/female click-edge logic, one-reuse off-cut rule, factory-edge labels.
1. Draw floor polygon (mm)
Click to add points · click first vertex to close · drag to move · right-click edge to add point · right-click vertex to remove · scroll to zoom · shift-drag to pan
| Bounding (mm) | Qty |
|---|---|
| 190 × 220 | 13 |
| 190 × 600 | 7 |
| 180 × 1380 | 1 |
| 127 × 1380 | 1 |
| 190 × 1380 | 1 |
| 53 × 600 | 1 |
| 10 × 220 | 1 |
Cut dimensions show the bounding box of each cut piece. Non-rectangular (angled) cuts are grouped by their enclosing rectangle.
Industry guide: each plank has 4 factory edges; cross-cuts yield 2 usable pieces. End-of-row offcuts ≥ 300 mm feed the next row only when the stagger rule holds. Scrap segments with two cut ends are waste.
